Electronic Dynamometer Digital Tension Thrust Gauge Tester Mask Mension Testing Machine Push Pull Pressure 2N 5N 10N 500N -------- ,Accurate & Efficient Force Measurement

<p>High precision and high resolution;</p><p>Three measurement mode for selection(Real time,Peak,First peak);</p><p>N(Newton),Kg (Kilogram) , Lb (Pound) and Oz(Ounce) four units for selection and conversion.</p><p>Setting function of acceleration----User can input at your option the accurate value of acceleration at the using place so as to make the testing and unit conversion be more accurate.</p><p>Upper and lower limits can be set for statistic analysis. The buzzer will alarm if exceeding the limits.</p>

• Minimum force value shielding function: the data within the set minimum range can be shielded;
• Automatic shutdown function: The automatic shutdown time can be set, and the automatic shutdown can achieve a point saving effect when there is no operation for a long time.
• Automatic backlight, buzzer alarm function
• Dynamometer 10N
• Sensor structure :Inner sensor
• Accuracy:±1%
• Power : 2 AAA batteries 1.5V(NOt include)
• Working temperature :5-35
• Transport temperature :-10-60
• Relative humidity :15%-80%RH
• Working conditions :No vibration source around and no corrosive environment.
• Dimensions :124*60*31(mm)
• Net weight :400g
• Digital Force Gauge
• 1. Digital display push-pull force meter is a small, simple, multi-functional and high-precision push and pull test instrument, which is widely used in electronic appliances, construction hardware, light industrial textiles, auto parts, lighters and other ignition devices, fire equipment, pen making Push-pull load, insertion force test, destructive test of locks, fishing gear, chemical industry, power machinery, scientific research institutions and other industries.
• 2. The digital display has high resolution, fast sampling speed, and easy to use.
• 3. It is a new generation of high-efficiency and high-precision push-pull test instrument.
• Pull Push 20N
• 1. Real-time mode
• Turn on the measurement interface, the system defaults to real-time measurement mode, and no mode is displayed on the screen.
• In this mode, the displayed measured value will change along with the load.
• 2. Peak mode
• Press the "PEAK" key, and the word "P" displayed on the screen is the peak mode. In this mode, the displayed measurement value is the maximum value. (When measuring again, if the measured value is lower than the previous maximum value, the displayed measured value will not change;
• if the measured value is higher than the previous maximum value, the displayed measured value will update and change.)
• 3. First peak mode
• Press the "PEAK" key, and the words "P" and "T" are displayed on the screen at the same time is the first peak mode.
• In this mode, the instrument only displays the first peak value measured in a period of time, and the measured value will not be displayed again.
• If there is a change, press the "ZERO" key to clear it before testing again.
• battery power;
• The screen simultaneously displays "P" and "T" as the first peak mode, indicating that the first peak value measured within a period of time is recorded; the screen displays a single "P" as the peak mode, indicating that the measured period of time is recorded Maximum force value; press "PEAK" key to switch between peak and first peak mode freely.
• unit display;
• measurement force value display;
• Push-pull force: the upper arrow shows the pulling force, and the lower arrow shows the pushing force.
• Electronic Dynamometer Digital Tension Thrust Gauge Tester Mask Mension Testing Machine Push Pull Pressure 2N 5N 10N 100N 500N
